the right and also the left turning-point separate adjustable
variable scann speed
several extending options refering to the application
Examples of applications:
monitoring of bulk goods on conveyors as well as each application where temperature profile registration is necessary.
Technical datas:
Scann angle
5 - 60° adjust.
Scann speed
25° - 120°/sec. adjust.
Supply voltage
24 V DC/AC
Current input
300 mA
Dimensions H / W / D
68 x 70,5 x 210 mm
Weight
1 kg (2,20 lbs)
Operating temperature
0 - 60°C (32 - 140°F)
Protection class
IP 65 (with protection window)
Mode of operation
continuous measurement: scann equipment working continuous single measurement: start through external signal for one scann manual: adjustment of scann-mirror for measurement at a fixed point
Options:
Angle - output
scann-angle as an analog output 0/4 - 20 mA = 0 - 60°
